immrax: A Parallelizable and Differentiable Toolbox for Interval Analysis and Mixed Monotone Reachability in JAX

ADHS 2024

Akash Harapanahalli\(^\dagger\), Saber Jafarpour\(^*\), Samuel Coogan\(^\dagger\)

\(^\dagger\)School of Electrical and Computer Engineering, Georgia Institute of Technology

\(^*\)Department of Electrical, Computer, and Energy Engineering, University of Colorado, Boulder

July 2, 2024

Acknowledgements

Saber Jafarpour
saberjafarpour.github.io

Advisor: Samuel Coogan
coogan.ece.gatech.edu

Motivation

Motivation: Safety of Neural Network Controlled Feedback Systems

  • Efficiently and scalably certify neural network controlled systems
  • Simple enough to train neural network controllers with safety guarantees

Reachability

Given a set of possible initial states \(\mathcal{X}\) and possible disturbances \(\mathcal{W}\), show that the set of all possible states \(\mathcal{R}(t,\mathcal{X},\mathcal{W})\) does not hit unsafe states \(\mathcal{A}\) while reaching goal states \(\mathcal{G}\).

Invariance

Show that a set of possible states \(\mathcal{X}\) is \(\mathcal{W}\)-robustly forward invariant, i.e., trajectories starting in \(\mathcal{X}\) remain in \(\mathcal{X}\) for all future time.

Interval Analysis for Neural Network Controlled System Robustness

Our Approach:

  • Interval analysis for general nonlinear systems analysis + neural network verification tools [1]
  • Scalable in state dimension compared to existing tools

Why we built immrax

No existing interval analysis tool supported either:

  1. GPU processing/parallelization, for rapid, batched verification online or in-the-loop
  2. Automatic differentiability, for implementation in the training loop

A interval analysis toolbox supporting these features could potentially be useful in other applications beyond learning-enabled systems.

Background: Interval Analysis

Inclusion Functions

Definition (Inclusion Function)

Given a map \(f:\mathbb{R}^n\to\mathbb{R}^m\), the map \(\mathsf{F}=[\underline{\mathsf{F}},\overline{\mathsf{F}}]\) is an inclusion function [2] for \(f\) if \[\begin{align*} \underline{\mathsf{F}}(\underline{x},\overline{x}) \leq f(x) \leq \overline{\mathsf{F}}(\underline{x},\overline{x}), \end{align*}\] for every \(x\in[\underline{x},\overline{x}]\).

Definition (Interval)

An interval \([\underline{x},\overline{x}]\subset\mathbb{R}^n\) is defined as the closed and bounded set \[ \begin{align*} \{x\in\mathbb{R}^n : \underline{x}\leq x\leq \overline{x}\}, \end{align*} \] where \(\leq\) is element-wise.

Minimal Inclusion Function

Definition (Minimal Inclusion Function)

Given \(f:\mathbb{R}^n\to\mathbb{R}^m\), \(\mathsf{F}\) defined by \[ \underline{\mathsf{F}}_i(\underline{x},\overline{x}) = \inf_{x\in[\underline{x},\overline{x}]} f_i(x), \ \overline{\mathsf{F}}_i(\underline{x},\overline{x}) = \sup_{x\in[\underline{x},\overline{x}]} f_i(x), \] is called the minimal inclusion function of \(f\).

Example (Arithmetic)

\[ \begin{align*} &[\underline{a},\overline{a}] + [\underline{b},\overline{b}] = [\underline{a}+ \underline{b}, \overline{a}+ \overline{b}] \\ &[\underline{a},\overline{a}]\cdot[\underline{b},\overline{b}] := [\min \{\underline{a}\underline{b},\underline{a}\overline{b},\overline{a}\underline{b},\overline{a}\overline{b}\}, \\ & \quad \max\{\underline{a}\underline{b},\underline{a}\overline{b},\overline{a}\underline{b},\overline{a}\overline{b}\} \end{align*} \]

  • Can define for primitive functions like \(\sin\), \(\exp\), \(x^n\), \(1/x\)
  • Generally computationally intractible

Example (Monotone)

Let \(f\) be monotone wrt \(\leq\). \[ \begin{align*} \underline{\mathsf{F}}_i(\underline{x},\overline{x}) &= \min\{f_i(\underline{x}),f_i(\overline{x})\}, \\ \overline{\mathsf{F}}_i(\underline{x},\overline{x}) &= \max\{f_i(\underline{x}),f_i(\overline{x})\}. \end{align*} \]

Example (Continuous)

\(\mathcal{S}= \{\text{critical points}\}\cap[\underline{x},\overline{x}]\) \[ \begin{align*} \underline{\mathsf{F}}_i(\underline{x},\overline{x}) &= \min_{x\in \mathcal{S}\cup \{\underline{x},\overline{x}\}} f_i(x), \\ \overline{\mathsf{F}}_i(\underline{x},\overline{x}) &= \max_{x\in \mathcal{S}\cup \{\underline{x},\overline{x}\}} f_i(x). \end{align*} \]

Building Inclusion Functions: Natural Inclusion Function

Definition (Natural Inclusion Function)

Let \(f = f_1 \circ \cdots \circ f_\ell\) be the composition of functions/operators \(f_i\), with inclusion functions \(\mathsf{F}_i\). Then \[\begin{align*} \mathsf{F}(\underline{x},\overline{x}) = (\mathsf{F}_1\circ \mathsf{F}_2\circ\cdots\circ \mathsf{F}_\ell)(\underline{x},\overline{x}), \end{align*}\] is a natural inclusion function of \(f\).

Example

Let \(f(x) = \sin(x^2)\). Let \(\textsf{SIN}\), \(\textsf{POW}_2\) be the minimal inclusion functions of \(\sin(x)\) and \(x^2\). \[\begin{align*} \mathsf{F}(\underline{x},\overline{x}) = \textsf{SIN}(\textsf{POW}_2(\underline{x},\overline{x})) \end{align*}\] is an inclusion function for \(f\).

  • Simple strategy to build inclusion functions for general mappings through composition

immrax.inclusion: Interval Analysis in JAX

Basics of JAX [3]: A Numerical Computation Library for Python

jit(f): Just-in-time Compilation

Compiles f upon its first execution

vmap(f): Vectorizing/Parallelizing

Vectorizes f along specified axis of input array

{jvp,vjp,jacfwd,grad}(f): Automatic Differentiation

Forward- or Reverse-mode autodiff using JVP/VJP

  • Key Feature: These transformations are arbitrarily composable.

Basics of JAX [3]: A Numerical Computation Library for Python

import jax
import jax.numpy as jnp

def f (x) :
  return jnp.sin(x**2)

f_grad = jax.grad(f)
print(f_grad(1.))
1.0806046
  • Key Feature: These transformations are arbitrarily composable.

Internals of JAX [3]

  • Traces functions into JAX programs dependent on input shapes and primitives
  • Functionality is added by an interpreter, which binds each primitive into their desired behavior
import jax
import jax.numpy as jnp

def f (x) :
  return jnp.sin(x**2)

jax.make_jaxpr(f)(jnp.ones(5))
{ lambda ; a:f32[5]. let
    b:f32[5] = integer_pow[y=2] a
    c:f32[5] = sin b
  in (c,) }

immrax.inclusion Module: A JAX Interpreter for Interval Analysis

Interval Class

lower and upper attribute for lower and upper bound of interval.

natif(f): Natural Inclusion Function

Traces f into a JAX program, and interprets primitives using their minimal inclusion functions.

Example \(f(x) = \sin(x^2)\)

{ lambda ; a:f32[5]. let
    b:f32[5] = integer_pow[y=2] a
    c:f32[5] = sin b
  in (c,) }
{ lambda ; a:f32[5]. let
    b:f32[5] = integer_pow[y=2] a
    c:f32[5] = sin b
  in (c,) }
{ lambda ; a:f32[5]. let
    b:f32[5] = integer_pow[y=2] a
    c:f32[5] = sin b
  in (c,) }

immrax.inclusion Module: A JAX Interpreter for Interval Analysis

import jax
import jax.numpy as jnp
from immrax import natif, interval

def f (x) :
  return jnp.sin(x**2)

F = natif(f)
print(F(interval(-0.5, 0.5)))
[(0., 0.24740396)]
  • immrax is fully compatible with the JAX ecosystem, Interval is registered as a Pytree node
  • natif is fully composable with all other JAX transformations

Example: Jacobian-based Inclusion Function

Definition (Jacobian-Based Inclusion Function)

Let \(f:\mathbb{R}^n\to\mathbb{R}^m\) be differentiable, with inclusion function \(\mathsf{J}\) for its Jacobian as \(\frac{\partial f}{\partial x}(x) \in \mathsf{J}(\underline{x},\overline{x})\) for every \(x\in[\underline{x},\overline{x}]\). Let \({\mathring{x}}\in[\underline{x},\overline{x}]\).

\[ \begin{align*} \mathsf{F}(\underline{x},\overline{x}) = [\mathsf{J}(\underline{x},\overline{x})]([\underline{x},\overline{x}] - {\mathring{x}}) + f({\mathring{x}}) \end{align*} \]

is a Jacobian-based inclusion function of \(f\).

import jax
import jax.numpy as jnp
from immrax import natif

def jacif (f) :
  J = natif(jax.jacfwd(f))
  def F (ix, xc) :
    return J(ix)@(ix-xc) + f(xc)

immrax.embedding: Bounding Nonlinear Systems

immrax.embedding Module: Bounding Nonlinear Systems

Definition (Embedding System)

Given a nonlinear system \(\dot{x} = f(x,w)\), an inclusion function \(\mathsf{F}(\underline{x},\overline{x},\underline{w},\overline{w})\) induces the embedding system \[ \begin{aligned} \dot{\underline{x}}_i = \big(\underline{\mathsf{E}}(\underline{x},\overline{x},\underline{w},\overline{w})\big)_i := \big(\underline{\mathsf{F}}(\underline{x},\overline{x}_{i:\underline{x}},\underline{w},\overline{w})\big)_i,\\ \dot{\overline{x}}_i = \big(\overline{\mathsf{E}}(\underline{x},\overline{x},\underline{w},\overline{w})\big)_i := \big(\overline{\mathsf{F}}(\underline{x}_{i:\overline{x}},\overline{x},\underline{w},\overline{w})\big)_i. \end{aligned} \]

  • \(2n\)-dimensional monotone dynamical system that “contains” the original system
  • Evaluates inclusion function separately on each face of the interval \([\underline{x},\overline{x}]\)
  • \(x(t)\in [\underline{x}(t), \overline{x}(t)]\), for \(x_0\in[\underline{x}_0,\overline{x}_0]\)
  • immrax.ifemb transforms a System into an EmbeddingSystem

Embedding System Trajectory

\[ x_0\in[\underline{x}_0,\overline{x}_0] \implies x(t) \in [\underline{x}(t),\overline{x}(t)] \]

Example: Robust Optimal Control of a Pendulum

Consider a forced, damped pendulum

\[ ml^2\ddot{\theta} + b\dot{\theta} + mgl\sin(\theta) = \tau, \]

The torque \(\tau := (1 + w)u\):

  • \(u\in\mathbb{R}\) is the desired torque input
  • \(w\in[\underline{w},\overline{w}] := [-0.01,0.01]\) is a bounded multiplicative disturbance

\[ \dot{x} = f(x,u,w) = \left[\begin{matrix} x_2 \\ \frac{(1 + w)u - bx_2}{ml^2} - \frac{g}{l}\sin x_1 \end{matrix}\right] \]

The goal is to stabilize the pendulum from the bottom to a specified region at the top.

class Pendulum (immrax.System) :
  def __init__(self, m=0.15, l=0.5, b=0.1) :
    self.evolution = 'continuous'; self.xlen = 2
    self.m = m; self.l = l; self.b = b

  def f(self, t, x, u, w) :
    return jnp.array([
      x[1],
      (((1 + w[0])*u[0] - self.b*x[1]) /
          ((self.m) * self.l**2)) - (g/self.l)*jnp.sin(x[0])
    ])
sys = Pendulum()

Example: Inclusion Function for the Pendulum

With a closed loop policy \(\pi(t,x) = K(x(t) - x_\mathrm{nom}(t)) + u_\mathrm{ff}(t)\), the following is an inclusion function for \(f(x,\pi(t,x),w)\),

\[ \begin{align*} [\textsf{F}^\pi(t,\underline{x},\overline{x},\underline{w},\overline{w})] := &\, ([\textsf{J}_x] + [\textsf{J}_u]K)([\underline{x},\overline{x}] - x_\mathrm{nom}(t)) \\ % &+ [\textsf{M}_u^\mathcal{O}]([\ulu,\olu] - \mathring{u}) & + [\textsf{J}_w]([\underline{w},\overline{w}] - w_\mathrm{nom}(t)) \\ & + f(x_\mathrm{nom}(t),u_{\mathrm{ff}}(t),w_\mathrm{nom}(t)), \end{align*} \]

where \(\mathsf{J}\) is from the Jacobian-based inclusion function.

Once we have the inclusion function \(\mathsf{F}\), the immrax.ifemb transform automatically builds the induced embedding system.

sys_mjacM = immrax.mjacM(sys.f)

def F (t, x, w, *, K, nominal) :
  tc, xc, uc, wc = nominal
  Jt, Jx, Ju, Jw = sys_mjacM(t, x, immrax.interval(uc), w,
                              centers=(nominal,))[0]
  return (
    (Jx + Ju @ immrax.interval(K)) @ (x - xc)
    + Jw @ (w - wc) + sys.f(tc, xc, uc, wc)
  )

embsys = immrax.ifemb(sys, F)

Example: Optimization Problem to Control the Pendulum

We build the following problem, \[ \begin{aligned} \min_{u_\mathrm{ff}, K} &\sum_{i=1}^N |u_{\mathrm{ff}}(t_i)|^2 + \|K\|_F^2 + \sum_{i=1}^N \|\overline{x}(t_i) - \underline{x}(t_i)\|_2^2 \\ \text{s.t.}& \ \ \underline{x}_f \leq \underline{x}(t_j),\ \ \overline{x}(t_j) \leq \overline{x}_f, \ \ j=N_e,\dots,N, \ \\ & \underline{x}(0) = \overline{x}(0) = (0, 0), \\ & \left[\begin{matrix} \underline{x}(t_{i+1}) \\ \overline{x}(t_{i+1}) \end{matrix}\right] = \left[\begin{matrix} \underline{x}(t_{i}) \\ \overline{x}(t_{i}) \end{matrix}\right] + \Delta t \textsf{E}(t_i,\underline{x}(t_i),\overline{x}(t_i),\underline{w},\overline{w}). \end{aligned} \]

  • Embedding system is discretized with step \(\Delta t\).
  • Starts at \(\underline{x}(0) = \overline{x}(0) = 0\)
  • Must end in target set \([\underline{x}_f,\overline{x}_f]\), stay for \(t\in[N_e\Delta t, N\Delta t]\)
# Objective function
def obj (u) :
    x = rollout_cl_embsys(u)
    return jnp.sum(u**2) + jnp.sum((x[:,2:] - x[:,:2])**2)

# Inequality constraints
def con_ineq (u) :
    x = rollout_cl_embsys(u)
    return jnp.concatenate(((x[Ne:,:2] - xfl).reshape(-1),
                            (xfu - x[Ne:,2:]).reshape(-1)))
  • rollout_cl_embsys takes u containing \(K\) and \(u_\mathrm{ff}\) (at sampled steps), returns Euler integration on embsys using jax.lax.scan

Example: Setting up IPOPT Using Automatic Differentiation

# Objective Gradient
obj_grad = jax.grad(obj)
# Objective Hessian
obj_hess = jax.jacfwd(jax.jacrev(obj))
# Constraint Jacobian
con_ineq_jac = jax.jacfwd(con_ineq)
# Constraint Hessian
con_ineq_hess = jax.jacfwd(jax.jacrev(con_ineq))
# Constraint Hessian-Vector Product
def con_ineq_hessvp (u, v) :
  def hessvp (u) :
    _, hvp = jax.vjp(con_ineq, u)
    return hvp(v)[0]
  return jax.jacrev(hessvp)(u)
  • These can all be JIT compiled for rapid execution
  • True values, not numerical estimations

Example: Solving the Problem Using IPOPT

cons = [ {'type': 'ineq', 'fun': con_ineq,
  'jac': con_ineq_jac, 'hess': con_ineq_hessvp}, ]

res = minimize_ipopt(obj, jac=obj_grad, hess=obj_hess, x0=u0,
  constraints=cons, options=ipopt_opts)

\(5.262\) seconds, \(100\) iterations

Further Applications of immrax

Revisiting the Neural Network Verification Problem

\[ % \begin{xalignat*}{2} \label{eq:vehicle} % \dot{p}_x &= v \cos(\phi + \beta(u_2)), & \dot{\phi} &=v\sin(\beta(u_2)),\\ % \dot{p}_y &= v \sin(\phi + \beta(u_2)), & \dot{v} &= u_1. % \end{xalignat*} \begin{align*} \dot{p}_x &= v \cos(\phi + \beta(u_2)), \\ \dot{p}_y &= v \sin(\phi + \beta(u_2)), \\ \dot{\phi} &=v\sin(\beta(u_2)), \\ \dot{v} &= u_1, \\ \beta(u_1) &= \arctan \left(\frac{1}{2}\tan(u_2)\right). \end{align*} \]

  • Controlled by \(4\times 100\times 100\times 2\) ReLU network mimicking stabilizing MPC
  • Inclusion function from [1], ReachMM
# Part. ReachMM immrax CPU immrax GPU
\(1^4 = 1\) \(.0476\) \(.0112\) \(.0178\)
\(2^4 = 16\) \(.690\) \(.143\) \(.0207\)
\(3^4 = 81\) \(3.44\) \(.627\) \(.0306\)
\(4^4 = 256\) \(11.0\) \(1.44\) \(.0489\)
\(5^4 = 625\) \(27.1\) \(4.60\) \(.095\)
\(6^4 = 1296\) \(55.8\) \(11.1\) \(.198\)

Training Certifiably Robust Neural Network Controllers (in progress)

  • If \(\underline{\mathsf{E}}(\underline{x},\overline{x},\underline{w},\overline{w}) \geq 0\) and \(\overline{\mathsf{E}}(\underline{x},\overline{x},\underline{w},\overline{w}) \leq 0\), then \([\underline{x},\overline{x}]\) is \([\underline{w},\overline{w}]\)-robustly forward invariant.

    \[ \mathcal{L}(\pi,\eta) = \operatorname{ReLU}(\overline{\mathsf{E}}(\underline{x},\overline{x},\underline{w},\overline{w}) + \varepsilon) + \operatorname{ReLU}(-\underline{\mathsf{E}}(\underline{x},\overline{x},\underline{w},\overline{w}) + \varepsilon) \]

Nonlinear segway model

Platoon up to 56 states

Conclusions

  • Interval analysis is an automated, scalable tool to analyze robustness of general functions.
  • immrax provides a JAX interpreter natif for the natural inclusion function, and an Interval class compatible with the rest of JAX.
  • Simple composable API as a function transformation.
  • Automatic differentiation can solve robust optimal control problems and train certified robust neural network controllers.
  • JIT compilation/GPU parallelization improves efficiency/scalability compared to previous work.

Documentation: immrax.readthedocs.io

References

[1]
S. Jafarpour, A. Harapanahalli, and S. Coogan, “Efficient interaction-aware interval analysis of neural network feedback loops,” IEEE Transactions on Automatic Control, pp. 1–16, 2024, doi: 10.1109/TAC.2024.3420968
[2]
L. Jaulin, M. Kieffer, O. Didrit, and É. Walter, Applied interval analysis. Springer London, 2001. doi: 10.1007/978-1-4471-0249-6
[3]
J. Bradbury et al., “JAX: Composable transformations of Python+NumPy programs.” 2018. Available: http://github.com/google/jax
